Новый Мобильная дробилка Polygonmach PMVS-70 Mobile screener, crusher, washer screen, screw washer, v

MOBILE SAND MAKER

Feeding Hopper : 10 m3

Crusher Feeding Belt Conveyor 800*9000mm

VSI700 Vertical Shaft Impact Crusher 132kw

Vibrating Screen 2 Decks 1600x5000mm 11 kw

Feedback conveyor 600*8000mm

Stockpile Conveyors 600*8000mm

Mobile Chassis 2 Axles-Compacible With EU Road Regulations

Automation -PLC- with Tablet and PC Controlled

Industrıal Paint on 1 Layer Linings-120-140 Micron- Barriers-Ladders-Platfroms Galvanised

PLANT DETAIL

Production Capacity 40-60 tph 0-5mm

Maximum Feeding Size 50mm

Feeding Height 3.8 meters

Main Configuration VSI Crusher + Vibrating Screen

Total Motor Power 165 kW

Electric Generator Requirement 350 kVA

Weight of the plant 31 Tonnes

Sizes of the plant 14(L) x 3 (W) x 4.2(L) meters

Chassis Type Single chassis on wheels

Production Capacity 100-150 tph

Maximum Feeding Size 50mm

FEEDER PROPER FOR HEAVY DUTY

Dimensions : 900x4100 mm

Bunker : 15 m³

Capacity : 150 to 200 tons / hour

Grid Length : 1160 mm

Main Body Sheet : 20 mm.

Weight : 5.5 tons.

Number of springs : 111 ea

Type of Bypass : Flat grid type (throttle transfer)

Grill casting : 16-18 mn. 1,5 cr.

Type of Bunker : With flat ramp climbing

Anchorage slots : pin click - fit

Bypass chute : With rear additional saddle

2-Model : VSI 700 -CR

Max Feed : 35 mm. Hard Condition

Rotor Diameter : 760 mm. / Off Std. Rotor

Rotor Speed : 50-70 m / s.

Drive : 132 kW / 1500 rpm.

Capacity : 40-60 tons / hour 0-5 sand production at 5-32 mm feed.

Total Capacity : 80-120 tons / hour

Weight : 8,500 kg

Rotor Diamond Inserts (Two-row - 6 pcs Ductile Iron Tungsten Carbide Tipped)

Other Wear Parts (2 Molybdenum, 22 Chrome Alloy Castings)

Electric Motorized Hydraulic Unit (Used for Belt tensioning and Upper Body Lifting.)

One-sided maintenance platform with ladder.

Drive pulley for two separate speeds (1400 rpm - 1600 rpm)

Vibration sensor switch

Maintenance Crane

Crusher Feeding Belt conveyor

Rated sizes : 800 x 9000 mm

Motor power : 7 kw 1500 d/d

Power Transmission : Motorized Reducer

Drive drum : 273 Vulcanized Rubber Coating

Tail drum : Angle process over pipe

Body Construction : Sheet Metal Body

Rubber Tension System : SNH type sliding bedding

Carrier : triplet assembly pedestal

Group of turning roll : single hanger system

Type of reducer : İ-MAK reducer

Band rubber : 5 layers of 10 mm EP-125 eksaş conveyor

Drive bearings : UCF type with special mat

Roll Ball Bearings : 6204 ZZ series

Drum Construction : PSV ring fedeer pressing collar

VIBRATING SCREENING

Rated sizes : 1600 x 5000 mm

Motor power : 11 kw 1500 d/dk

Drive system : with conventional drive, with 4 weights

Amount of Ball Bearing : 2 ea

Number of Ball Bearing : 22328 (FAG T41 Ball Bearing with Vibration Amplitude)

Screening area : Double Deck

Number of Vibration amplitude : 6-8 amplitude, Linear Free Eliptic

Number of Springs : 12 ea

Front chute : with 6 mm rotary chute

Bottom chute : flat discharge chute

Type of power transmission : belt pulley couples

Body Construction : Heavy duty type (12mm ST37 Ereğli Iron Steel Sheet Metal)

Seamless manufacturing bolted frame construction

Stone Box front grooves, no wear, valve front groove

Stockpile Conveyor Belt

Rated sizes : 600 x 8000 mm

Motor power : 5 kw 1500 d/d

Power Transmission : Motorized Reducer

Drive drum : 273 Vulcanized Rubber Coating

Tail drum : Angle process over pipe

Body Construction : Sheet Metal Body

Rubber Tension System : SNH type sliding bedding

Carrier : triplet assembly pedestal

Group of turning roll : single hanger system

Type of reducer : İ-MAK reducer

Band rubber : 5 layers of 10 mm EP-125 eksaş conveyor

Drive bearings : UCF type with special mat

Roll Ball Bearings : 6204 ZZ series

Drum Construction : PSV ring fedeer pressing collar

Feedback Conveyor Belt

Rated sizes : 600 x 8000 mm

Motor power : 5 kw 1500 d/d

Power Transmission : Motorized Reducer

Drive drum : 273 Vulcanized Rubber Coating

Tail drum : Angle process over pipe

Body Construction : Sheet Metal Body

Rubber Tension System : SNH type sliding bedding

Carrier : triplet assembly pedestal

Group of turning roll : single hanger system

Type of reducer : İ-MAK reducer

Band rubber : 5 layers of 10 mm EP-125 eksaş conveyor

Drive bearings : UCF type with special mat

Roll Ball Bearings : 6204 ZZ series

Drum Construction : PSV ring fedeer pressing collar

Main Chassis

Chassis : NPI 380

Chassis Legs : NPU 160 Closed Box

Leg Joint Plates : 15 - 20 mm ST 37

Cross Joints : NPU 100

Platform :Reciprocal Folable Walking Ways and Barriers, Ladders

Transport Length : 10500 mm

Transport Width : 2675 mm

Transport Height : 4000 mm

Axle : TS-2300 Ali Osman

Brakes : Brake Pads

Whell/Alloy : 4 PCS 12/R/22.5

Weight : 8700 Kg
